MOTOR | Bosch Performance Line CX (Gen 4). 85 Nm max Torque, 250 W nominal power, 2.79 kg 4 Power settings including progressive eMTB mode which automatically adjusts the support |
BATTERY | Bosch 625 Wh internal PowerTube. Reaches full charge in 5 hours with supplied 4A Compact Charger, 80% charge from 0 in 2.5 hours |
DISPLAY | Bosch Purion |
COLOUR | Matt Black with Burnt Orange & Slate |
CASSETTE | SRAM XG-1275 Eagle, 10-52, 12 Speed |
FRAME | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts |
CHAIN | SRAM GX Eagle, 12 Speed |
FORK | Fox Float 38, Factory 27.5", 180mm Travel, 44mm Offset with Grip 2 Damper and custom tune, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle |
CRANKSET | Race Face Affect E-Bike, 165mm, ISIS with X-SYNC Direct Mount 34T for Bosch Gen 4, Black |
REAR SHOCK | Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating |
BOTTOM BRACKET | N/A |
HEADSET | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
SEATPOST | Crank Bro High-Line 3, 30.9mm, M/L 150mm Travel, XL 170mm Travel, High-Line Ball Socket Remote Lever |
REAR HUB | DT Swiss 350 Straightpull with 24T Ratchet System, 12mm x 148mm, 6 Bolt with Magnet carrier, 28 Hole |
SADDLE | Whyte Custom, Triple Panel Design |
FRONT HUB | DT Swiss 350, 15mm x 110mm, Centre-Lock, 28 Hole |
HANDLEBAR | Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide |
SPOKES | DT Swiss Hybrid triple butted 2.34mm/1.8mm/2.0mm, Black Stainless, DT Pro Lock Squorx Nipples |
STEM | Race Face Atlas, 35mm Bar Bore, 35mm Extension |
RIMS | DT Swiss Hybrid 30, Sleeved Joint, 28 Hole |
GRIPS | Whyte Lock-on V Grip |
TYRE | Maxxis Assegai WT, TR, 27.5" x 2.5" 120TPI, EXO + Sidewall Protection, 3C Maxx Terra, Dual Compound, Folding Bead, Front, Maxxis Assegai WT, TR, 27.5" x 2.5" 120TPI, Double Down casing, 3C Maxx Terra, Dual Compound, Rear |
BRAKES FRONT | SRAM Code RSC, 4 Pot with Sintered Metal Pads, 220mm Rotor |
SHIFT LEVERS | SRAM X01-E Eagle, Single Click, MMX, 12 Speed |
BRAKES REAR | SRAM Code RSC, 4 Pot with Sintered Metal Pads, 200mm Rotor |
FRONT MECH | N/A |
BRAKE LEVERS | SRAM Code RSC, MMX |
REAR MECH | SRAM X01 Eagle, 12 Speed |
WEIGHT | TBC |
