COLOUR | Gloss silver with matt black | CASSETTE | SRAM XS-1275 Eagle, 10-52T, 12 speed |
---|
FRAME | 6061 alloy, hydroformed T6 aluminium, multi-butted, custom drawn, tapered headtube, internal cable routing, Shape.it Link and 12mm x 148mm Boost dropouts | CHAIN | SRAM GX T-Type Eagle, 12 speed |
---|
FORK | Fox Float 38 Performance, 160mm travel, 44mm offset with Grip damper, three-position adjustable, tapered steerer, 110mm x 15mm Boost, E-thru-axle | CRANKSET | Whyte, forged alloy, 155mm, direct mount 36T chainring |
---|
REAR SHOCK | Fox Float Performance DPS, EVOL LV, custom tuned for Whyte, three position adjustable compression and rebound damping | BOTTOM BRACKET | N/A |
---|
HEADSET | FSA No. 55/35 Orbit 1.5 ZS, 1.8in lower and 1 1/8in upper sealed cartridge bearings | SEATPOST | Crank Brothers HighLine 3, 30.9mm (sizes XS/S/M/L 150mm travel; size XL 170mm travel), Highline ball socket remote lever |
---|
REAR HUB | Alloy, e-bike specific, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole | SADDLE | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
---|
FRONT HUB | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 32 hole | HANDLEBAR | Whyte Custom 6061 alloy, 30mm rise, 35mm bar bore, 780mm wide |
---|
SPOKES | DT Swiss New Champion 2.0mm, black stainless, brass nipples | STEM | Whyte Enduro, 35mm extension, 35mm bar bore |
---|
RIMS | WTB HTZ i30 TCS 2.0 System, asymmetric, sleeved joint, super tough construction, tubeless ready, 32 hole | GRIPS | Whyte Enduro lock-on |
---|
TYRE | Maxxis Assigai WT, TR, 2.5in 120TPI, EXO+ casing, 3C Maxx Grip, Dual Compound, Front; Maxxis Minion DHR II WT, TR, 2.4in 120TPI, Double Down, 3C Maxx Terra, Dual Compound, folding bead, rear | BRAKES FRONT | SRAM Code R, four piston hydraulic with sintered metal pads, 220mm diameter disc rotor |
---|
SHIFT LEVERS | SRAM AXS Pod, two button MMX, 12 speed | BRAKES REAR | SRAM Code R, four piston hydraulic with sintered metal pads, 200mm diameter disc rotor |
---|
FRONT MECH | N/A | BRAKE LEVERS | SRAM Code R, MMX |
---|
REAR MECH | SRAM GX T-Type AXS, 12 speed | PEDALS | None |
---|
WEIGHT | 26.7kg (size M) |
---|
