COLOUR | Gloss silver | CASSETTE | Shimano Cues, 9 speed, 11-46T |
---|
FRAME | 6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts, chain stay kick stand mount | CHAIN | Shimano Cues 9 speed |
---|
FORK | Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, Post Mount with single eyelets for mudguards | CRANKSET | Shimano Cues 9 speed, 170mm, 40T chainring, with chain guard |
---|
REAR SHOCK | N/A | BOTTOM BRACKET | Kynamic BSA, square taper, 122.5mm, with torque sensor |
---|
HEADSET | No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed catridge bearings and front entry for cables | SEATPOST | Whyte 6061 alloy, 27.2mm diameter, two-bolt clamp |
---|
REAR HUB | Kynamic 250W, 36V, 45Nm 142mm power hub with replaceable freehub, 32 hole | SADDLE | Whyte Custom |
---|
FRONT HUB | Alloy, double sealed cartridge bearings, 12mm x 100mm thru-axle, 32 hole | HANDLEBAR | Whyte one piece bar and stem: 50mm extension, 720mm width, 20mm rise, seven degree backsweep, four degree upsweep |
---|
SPOKES | 2.0mm, PG, black stainless, brass nipples | STEM | N/A |
---|
RIMS | WTB STp I27 rims, 32 hole | GRIPS | Whyte Custom dual density lock-on |
---|
TYRE | Maxxis Reaver Tanwall 700 x 45c, EXO wire bead | BRAKES FRONT | Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor |
---|
SHIFT LEVERS | Shimano Cues 9 speed Rapidfire | BRAKES REAR | Tektro T3020 hydraulic, 1.8mm thick 180mm diameter disc rotor |
---|
FRONT MECH | N/A | BRAKE LEVERS | Tektro T3020 Clean Sweep Design, three finger comfort lever |
---|
REAR MECH | Shimano Cues 9 speed, Shadow Design and direct attachment | PEDALS | Fibre reinforced composite platform |
---|
WEIGHT | 15.5kg (size M) | | |
---|
