Frame
Size: XXS , XS , S
Alpha Silver Aluminium, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5 mm QR
Size:M , ML , L , XL , XXL
Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5 mm QR
Fork
Size: XXS
SR Suntour XCM 30, coil spring, lockout, preload, 100 mm QR, 100 mm travel, 26" wheel
Size:XS
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 80 mm travel
Size:S
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 27.5" wheel, 100 mm QR, 100 mm travel
Size:M , ML , L , XL , XXL
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel
Max compatible fork travel
100mm (XS & S: 490mm axle-to-crown, M & up: 509mm axle-to-crown)
Hub front
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Hub rear
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Skewer rear
152x5 mm QR
Rim
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Tyre
Size: XXS
Bontrager XR2 Comp, wire bead, 30 tpi, 26x2.20"
Size:XS , S
Bontrager XR2 Comp, wire bead, 30 tpi, 27.5x2.20"
Size:M , ML , L , XL , XXL
Bontrager XR2 Comp, wire bead, 30 tpi, 29x2.20"
Max tyre size
Frame: 29x2.20" (XS & S: 27.5x2.4") Fork: See manufacturer
Shifter
Shimano Altus M315, 8-speed
Front derailleur
Shimano Altus M315, 34.9 mm clamp, top swing, dual pull
Rear derailleur
Shimano Altus M310
Crank
Size: XXS
Prowheel TM-CY10, 36/22, 160 mm length
Size:XS , S , M
Shimano M315, 36/22, 170 mm length
Size:ML , L , XL , XXL
Shimano M315, 36/22, 175 mm length
Bottom bracket
Sealed cartridge, 73mm
Cassette
Shimano 8-speed, 12-32T
Chain
KMC Z8.3, 8 speed
Max. chainring size
1x/2x: 34T, 3x: 42T
Saddle
Bontrager Arvada, steel rails, 138 mm width
Seatpost
Size: XXS
Bontrager alloy, 31.6mm, 12mm offset, 300mm length
Size:XS , S , M
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Size:ML , L , XL , XXL
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length
Handlebar
Size: XXS , XS
Bontrager alloy, 31.8 mm, 5 mm rise, 690 mm width
Size:S , M , ML , L , XL , XXL
Bontrager alloy, 31.8 mm, 5 mm rise, 720 mm width
Stem
Size: XXS
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 35 mm length
Size:XS
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length
Size:S
Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size:M
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length
Size:ML , L
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 80 mm length
Size:XL , XXL
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 90 mm length
Head set
Semi-integrated, 1-1/8"
Brake
Tektro HD-M275 hydraulic disc, 180 mm rotor
Brake Set
Tektro HD-M275 hydraulic disc, 160 mm rotor
Weight
M - 13.97 kg / 30.81 lb
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).
