*Saddle | Size:S, M, ML, L, XL Bontrager Verse Comp, steel rails, 145 mm width |
---|
Size:S, M, ML, L, XL Verse Short Comp, steel rails, 145 mm width |
*Seatpost | Size:S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
---|
Size:S TranzX JD-YSP18, 100 mm travel, internal routing, 31.6 mm, 361 mm length |
Size:M, ML, L Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length |
Size:M, ML TranzX JD-YSP18, 120 mm travel, internal routing, 31.6 mm, 403 mm length |
Size:L, XL TranzX JD-YSP18, 150 mm travel, internal routing, 31.6 mm, 470 mm length |
Size:XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
*Handlebar | Size:S Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
---|
Size:M, ML, L, XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width |
Grips | Bontrager XR Trail Comp, nylon lock-on |
---|
*Stem | Size:S Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 50 mm length |
---|
Size:M, ML Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
Size:L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
Size:XL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
Head set | FSA IS-2, 1-1/8" top, 1.5" bottom |
---|
Brake | Shimano hydraulic disc, MT501 lever, MT500 caliper |
---|
Rotor size | Max brake rotor sizes – Frame: 160 mm, Fork: see fork manufacturer |
---|
