Frame
100 Series Alpha Aluminium, mudguard mounts, DuoTrap S-compatible, rim brake, 130x5 mm QR
Frame fit
Endurance
Hub front
Formula TK-31 alloy, 5x100 mm QR
Skewer front
Formula QR22
Hub rear
Formula TK-32 alloy, Shimano 8/9/10 freehub, 5x130 mm QR
Rim
Bontrager Tubeless Ready, 24-hole, 17 mm width, Presta valve
Tyre
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 c
Max tyre size
28c without mudguards, 25c with mudguards
Shifter
Shimano Claris R2000, 8 speed
Front derailleur
Shimano Claris R2000, 31.8 mm clamp
Rear derailleur
Shimano Claris R2000, medium cage, 34T max cog
Crank
Size: 47
Shimano RS200, 50/34 (compact), 165 mm length
Size:50, 52, 54
Shimano RS200, 50/34 (compact), 170 mm length
Size:56, 58, 60, 62
Shimano RS200, 50/34 (compact), 175 mm length
Bottom bracket
Shimano UN300, 68 mm, threaded cartridge, 110 mm spindle
Cassette
Shimano HG31, 11-32, 8 speed
Chain
Shimano Sora HG71, 8 speed
Pedal
Wellgo R199, nylon body, alloy cage
Max. chainring size
1x: 42t, 2x: 50/34
Saddle
Size: 47, 50, 52
Bontrager Verse Comp, steel rails, 155 mm width
Size:54, 56, 58, 60, 62
Bontrager Verse Comp, steel rails, 145 mm width
Seatpost
Size:47
Bontrager alloy, 27.2 mm, 12 mm offset, 250 mm length
Size:50, 52, 54, 56, 58, 60, 62
Bontrager alloy, 27.2 mm, 12 mm offset, 330 mm length
Handlebar
Size: 47
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 38 cm width
Size:50, 52
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 40 cm width
Size:54, 56
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 42 cm width
Size:58, 60, 62
Bontrager Comp VR-C, alloy, 31.8 mm, 100 mm reach, 124 mm drop, 44 cm width
Handlebar tape
Bontrager Gel Cork tape
Stem
Size: 47
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size:50
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Size:52, 54
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length
Size:56, 58
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 100 mm length
Size:60, 62
Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 110 mm length
Head set
FSA Integrated, sealed cartridge bearing, 1-1/8"
Brake
Alloy dual-pivot
Rotor size
Max brake rotor sizes: 160 mm front and rear
Weight
56 - 9.57 kg / 21.09 lb
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
